MΩ Tester 3587
  • MΩ Tester 3587

MΩ Tester 3587

□ Suitable for insulation resistance measurement of lithium ion secondary batteries
□ Test voltage ranging from 25V to 1000V with 1V resolution
INQUIRY
□ High-speed sampling: 50 or 60 times/sec.
□ Test voltage: DC 25~1000 V (resolution: 1V)
□ Resistance range: 2/20/200/2000 MΩ
□ Connection checking function available to prevent misjudgment due to bad connection
□ Compact & light: 205(W)×64(H)×169(D)mm, 1kg


Model      3587 - □
                                   ①

①Data Output
Code Description
X RS-232C
4 RS-232C + BCD (open collector)


Measuring Range




Product catalogue is available upon request.
